Quick Details

  • Place of Origin: Guangdong, China (Mainland)
  • Brand Name: SANWAY
  • Model Number: FP14000
  • FP14000: 7000W Extreme High Power Professional Subwoofer Amplifier
  • Type: Professional Ampliifer
  • Channel: 2
  • Heat sink: pure copper
  • Power Plug: American or European
  • Wideband voltage: 220v version can run from 135v to 265v voltage range
  • 110V: 110v version can run from 65v to 135v voltage range
  • Packing: 2 layers carton
  • Net weight: 12.5kg
  • Gross weight: 18kg

Packaging & Delivery

Packaging Details: FP14000 7000W Extreme High Power Professional Subwoofer Amplifier
double durable cartons; 59x57x18cm
Delivery Detail: upon receipt of deposit

 FP14000 7000W Extreme High Power Professional Subwoofer Amplifier







FP14000 Inside





FP14000 Amplifier Board





FP14000 Input Board





FP14000 Power Supply Board

Product Description

  FP14000 7000W Extreme High Power Professional Subwoofer Amplifier

ITEMFP7000FP9000FP13000FP14000FP6000QFP10000Q
Output Power20-20kHz, 1W with 1 khz
8ΩStereo Power(RMS)1450WX21600WX22350WX22350WX2625WX41350WX4
4ΩStereo Power(RMS)2800WX23000WX24400WX24400WX21250WX42100WX4
2ΩStereo Power(RMS)3500WX24500WX26500WX27000WX21500WX42500WX4
8ΩBridged Power(RMS)5600W6000W8800W8800W2500WX24200WX2
4ΩBridged Power(RMS)7000W9000W13000W14000W3000WX25000WX2
Frequency Response(+o/-0.3dB,1W/8Ω)20 Hz - 34 kHz
THD 20 Hz - 20 kHz for 1 W<0.1%
Signal-to-Noise Ratio>112 dBA
Channel separation (Crosstalk) at 1 kHz>70 dB
Input Connectors (per channel)3-pin XLR, electronically balanced
Output Connectors (per channel)Binding Posts 2-pole
ClassTD
TourClass ProtectionACL,IGM, AutoRamp, short circuit, DC voltage, turn-on/off transient, current inrush, sub/ultrasonic input
Operating voltage, 230 V / 115 V nominal130-265 V / 65-135 V selectable
Voltage Gain(dB)23, 26, 29, 32, 35, 38, 41, 44 dB selectable
Input impedance20 kOhm
Level adjustment (per ch.)Front-panel potentiometer, 31 position detented from -inf to 0 dB
Dimensions (W×H×D)483×88×396mm
Packing dimension560×180×500mm
Net weight(kg)13
Gross weight(kg)18
